The ProTee VX is one of the most popular ceiling-mounted launch monitors paired with GSPro -- thousands of courses, full ball and club data, and no subscription on the launch monitor side. But ProTee's GSPro integration runs through a specific license type and a connector flow that trips up most first-time owners.

This guide walks through the full setup in order: GSPro license conversion, ProTee Labs game-options configuration, the GSPro API connection, PC specs, VSync settings, putting setup, and the fixes for the two errors almost every VX owner sees on day one.

What You Need Before Starting

The VX talks to GSPro through ProTee Labs and the GSPro API. Confirm you have all of the following before opening any software:

• Mounted ProTee VX with the included Cat6 Ethernet cable connected to your PC (use the included USB 3.0--to--Ethernet adapter on a blue USB3 port if your network is already hardwired).
• ProTee Labs installed and activated on your Windows PC (Top Shelf Golf includes the activation code with your VX order).
• A GSPro license set to the ProTee VX hardware type. If you bought GSPro before owning the VX, you will need to convert your existing license -- see Step 2.
• A Windows PC that meets the GSPro requirements. ProTee recommends an NVIDIA RTX 3080 or better, 32 GB of RAM, and at least 20 GB of free storage for optimal 4K performance. The ProTee Labs minimum (64-bit Windows 10, Intel Core i7-8xxx, 8 GB RAM) is lower than what GSPro needs at higher resolutions.
• An internet connection for the license, downloads, and the GSPro API.

If you do not have a sim PC yet, our guide on whether you need a dedicated simulator computer walks through SurfThing prebuilds that are configured for GSPro out of the box.

Step 1: Confirm the VX Is Mounted and ProTee Labs Is Running

Before you open GSPro, make sure your hardware path is healthy.

1. Power on the ProTee VX with the red switch on the back of the unit.
2. Launch ProTee Labs on your PC. Go to Settings > Device, select ProTee VX from the device list, and click Connect.
3. Wait until the status in the upper right reads "CONNECTED."
4. If this is your first session, run through the camera calibration flow (place the calibration plate flat in the hitting area, level it with the included bubble level, click Calibrate System, then Calibrate World, and define your play area).
5. Hit a test shot. ProTee Labs should display ball speed, club speed, and the rest of the 24 data points.

If Labs cannot find the VX, the most common fix is to use the supplied USB-to-Ethernet adapter on a blue USB 3.0 port rather than a USB 2.0 port. ProTee's knowledge base also notes that the VX requires at least a 1 Gbit network connection over Cat6 or higher.

Step 2: Set Your GSPro License to ProTee VX

GSPro sells separate license types per launch monitor. Your license has to be tied to the ProTee VX hardware before it can talk to ProTee Labs.

1. Buy a GSPro license through TSG's GSPro product page.
2. If you already own a GSPro license for a different launch monitor (for example, a SkyTrak or Garmin license), open the GSPro License Conversion Tool and select ProTee VX as your new hardware. Per ProTee support, license conversion is the most common cause of "Connection Failed to GSPro" errors.
3. Install GSPro on the same Windows PC that runs ProTee Labs.
4. Make sure your GSPro install is up to date before continuing -- both ProTee Labs and GSPro push regular updates that affect the connector.

Step 3: Configure ProTee Labs Game Options

ProTee Labs is the bridge between the VX hardware and GSPro. The bridge is configured under Settings > Game Options.

1. In ProTee Labs, open Settings > Game.
2. Find the GSPro integration entry. Confirm the connector is enabled.
3. Leave the default host as localhost. ProTee's support team recommends not changing this unless their team specifically tells you to.
4. Save the settings and keep ProTee Labs running in the background.

Step 4: Open GSPro and the GSPro API Together

This is the step most first-time VX owners miss.

1. Launch GSPro on your Windows PC.
2. Launch the GSPro API as a separate program. The API is what ProTee Labs actually connects to -- GSPro by itself is not enough.
3. Per ProTee's knowledge base: "After activation, ensure that both the GSPro API and GSPro remain open while connecting in Labs settings under the Game Options."
4. In ProTee Labs, open Settings > Game Options and click Connect next to GSPro.
5. The connector should report a successful link. ProTee Labs status in GSPro will show your VX as the active launch monitor.

Step 5: Fix "Connection Failed to GSPro" Errors

The error message "Connection Failed to GSPro" is the single most common issue in the first session. ProTee support attributes it almost exclusively to license type. If you see it:

1. Open GSPro and click Change License Type.
2. Go to the GSPro License Conversion Tool and select ProTee VX.
3. Restart both GSPro and the GSPro API.
4. Retry the connection from ProTee Labs.

If the error persists, check that the GSPro API window is still open (it sometimes minimizes silently) and that no firewall is blocking the local connection. ProTee recommends connecting the VX directly to your PC's Ethernet port over the network for stability.

Step 6: Optimize GSPro Graphics for the ProTee VX

Once the connection is solid, ProTee's graphics-tuning guidance for GSPro on a VX comes down to a couple of settings.

1. Enable VSync in GSPro. Per ProTee support: enabling VSync prevents GSPro from grabbing more GPU than it needs, which can otherwise interfere with the VX connector. Press F in GSPro to toggle the FPS counter and verify your frame rate is stable.
2. Match GSPro resolution to your projector or display. Most home VX setups run 1080p; if you have a 4K projector and an RTX 3080 or better, you can run 4K.
3. Lower object detail and tree count if your frame rate dips below 60 fps. GSPro's default settings target high-end PCs.
4. For a dedicated GPU, make sure GSPro is running on the dedicated card rather than integrated graphics. On Windows: Settings > Gaming and add GSPro to the high-performance GPU list.

Putting with GSPro on the ProTee VX

Putting in GSPro on a VX has two quirks worth knowing.

Ball position. The ProTee VX detection area is approximately 25" x 21" (65 x 55 cm). ProTee support recommends marking a fixed spot on your hitting mat or floor where the ball should be placed for putting -- it keeps the unit reading consistently across sessions.

Green speed. Green speeds in GSPro can be fixed by the course or tournament setting and may not be user-adjustable. If your putts feel too fast or slow, try a different course or check the tournament settings before assuming the VX is wrong.

Why ProTee Labs and GSPro Show Different Numbers

You will sometimes see a different carry distance or apex height in ProTee Labs versus what shows up in GSPro on the same shot. This is expected.

Per ProTee's knowledge base: ProTee Labs and GSPro use different ball-flight models. Carry distances can vary between ProTee Labs (which uses the Driving Range physics), TGC 2019, GSPro, and other simulation software, plus factors like altitude, temperature, and humidity that some GSPro courses apply.

Two practical implications:

• When you compare your distances against PGA Tour averages, use the ProTee Labs Driving Range -- not a GSPro course -- because the Labs flight model is what ProTee tuned to the VX hardware.
• The club selected in GSPro overrides ProTee Labs' auto-detect during a round, so if Labs shows the wrong club, it usually means GSPro is forcing the selection. Change the club in GSPro, not in Labs.

Recommended PC Specs for GSPro + ProTee VX

ProTee publishes a baseline PC spec for the VX hardware itself, plus a higher recommendation for running GSPro at 4K.

If you would rather not build the PC yourself, the SurfThing prebuilt PCs are spec-matched to ProTee VX plus GSPro at 4K out of the box -- see our simulator PC guide.

Common ProTee VX + GSPro Issues and Quick Fixes

"Connection Failed to GSPro" in ProTee Labs

License-type mismatch. Open GSPro, click Change License Type, run the GSPro License Conversion Tool, and select ProTee VX. Restart GSPro and the GSPro API.

The wrong club shows up on a shot

When ProTee Labs is connected to GSPro, GSPro's selected club takes priority over Labs' auto-detect. Change the club in GSPro, not in Labs.

Frame rate drops in GSPro

Enable VSync in GSPro. Lower object detail / tree count. Confirm GSPro is running on your dedicated GPU instead of integrated graphics.

Does the VX work with GSPro multiplayer?

Yes. Per ProTee support, the VX works with all GSPro gameplay modes, including multiplayer. The game mode you choose in GSPro does not affect VX tracking or data quality.

Distances feel too short or too long

GSPro courses apply altitude, temperature, and humidity. Check the course settings, then compare against the ProTee Labs Driving Range, which uses ProTee's flight model rather than GSPro's.
